Outdoor Heating Cable
Product Description
Snow and ice can be very risky leading to accidents. Our heating cable is keeping the roads and surfaces free of snow and ice at all times
Snow melting/ De-icing cables /Mats
Depending upon the areas of application there exists two versions:
- Concrete pavements, driveways, exterior stairs, gutters, downspouts, roofs, terraces, road surfaces.
- Asphalt pavements or road surfaces. For temperatures up to 240°C for a short duration and safely above 150°C at which the asphalt is laid.
Techincal Details
- Linear Wattage Density: 30W/m (standard), 40W/m (on request)
- Rated Voltage: 230V, 50Hz
- Nominal Limit Temperature: 80°C
- Installation Temperature: -20°C
- Conductor: Twin core/Single core, Class-2 resistance alloy
- Core Insulation: Advance fluoropolymer or TPE
- Earth Shield: Copper shielding
- Outer Sheath: For type SMCC:XLPE while for SMCA: high temperature TPE
- Cold lead connection: Type- Y attachment (Up to 5m) Either side or one side depending upon single or twin configuration.
- Cable diameter: SMCC:6.5mm-7.5mm; SMCA:5mm-6mm
- Protection category: IPx7; UV resistant
Freeze Protection/ Pipe trace cables
Product Description
These heating cables are flexible and efficient with a consumption of 15W per linear meter. These cables are designed for domestic and commercial applications to prevent water from freezing. For better results, heating cable is flat shaped to have maximum contact with the object you need to protect
Features and Applications
- Used in pipe trace heating. Prevent water pipes from freezing. The in-built thermostat/temperature limiter will operate to switch ON at 5°c and switch OFF at 15°c.
- Can be used directly in green house and on pipes
