Thermostats
TouchApp
Wifi Control System
TouchApp control system is designed to control under floor heating systems over Wi-Fi. TouchApp is made especially for electrical heating systems in houses, business and buildings. The thermostat is also designed to be retro-fitted in order to replace the traditional old thermostats at the costumer house, without any demand for additional wiring or changing anything at the wall/wall box, just fixe it in standard wall box.
Features
- The thermostat is made of Glass for a clean&perfect design.
- Can be provided in any color (black or white as standard)
- Easy and unlimited days and hours of programming
- Can be controlled from any mobile device, like a smartphone or tablet, Android & Apple.
Specifications
-
Working voltage AC230V, 50HZ / AC 110V, 60HZ
-
Current load ≤16A
-
Temperature measurement Built-in sensor and external sensor
-
External sensor length 3m
-
Temperature control range 5 ºC ~ 40 ºC
-
Temperature sensing element NTC resistance
-
Grade of protection IP20C
-
Surface materialr Crystal glass
-
Installation Wall-inserted type
TouchMi
Touch Screen Thermostat
Product Description
The world’s most decorative functional thermostat.
TouchMi is designed to control under floor heating systems. TouchMi is made especially for electrical heating systems in houses, business and buildings.
The thermostat is also designed to be retro-fitted in order to replace the traditional old thermostats at the costumer house, without any demand for additional
wiring or changing anything at the wall/wall box, just fix it in standard wall box.
The thermostat is adjustable to required temperature from +5/+40C, and recommended controlling of electrical heating systems or on/off valve actuator used in water-based heating systems.
Features:
- Made of Glass for a clean&perfect design
- Can be provided in any color (black or white as
standard) - Non programmable thermostat
Specifications
-
Working voltage AC230V, 50HZ / AC 110V, 60HZ
-
Current load ≤16A
-
Temperature measurement Built-in sensor and external sensor
-
External sensor length 3m
-
Temperature control range 5 ºC ~ 40 ºC
-
Temperature sensing element NTC resistance
-
Grade of protection IP20C
-
Surface materialr Crystal glass
-
Installation Wall-inserted type
THR101
Electric Thermostat
Product Description
THR-101 is designed to control under floor heating systems, especially for electrical heating systems in houses, business and buildings.
THR-101 model is electronic thermostat for mounting in standard wall box, The thermostat is adjustable to required temperature from +5/+40 ºC, The LED shows
that the heat is On.
The thermostat is recommended controlling of electrical heating systems or on/off valve actuator used in water-based heating systems.
Specifications
-
Working voltage AC230V, 50HZ
-
Current load ≤16A
-
Temperature measurement Built-in sensor or external sensor
-
External sensor length 3m
-
Temperature control range 5 ºC ~ 45 ºC
-
Temperature sensing element NTC resistance
-
Grade of protection IP20C
-
Surface materialr PC engineering plastic
-
Installation Wall-inserted type
